FMV SS302 Flammability Burn Resistance Tester For Interior Materials

Basic Information

Place of Origin:	China
Brand Name:	AI
Certification:	ISO9001
Model Number:	HFT

Minimum Order Quantity:	1 set FMV SS302 Flammability Tester
Price:	Negotiable
Packaging Details:	FMVSS 302 Flammability Tester packed in veneer case.
Delivery Time:	30 days
Payment Terms:	Western Union, T/T, L/C, MoneyGram
Supply Ability:	100 sets FMVSS 302 Flammability Tester each month

Get Best Price Contact Now

Reference Standards:	FMV SS302, ISO 3795,ASTM D5132	Application Field:	Interior Materials
Gas Supply:	Propane	Dimension:	430 Mm (W) X 310 Mm (D) X 360 Mm (H)
Weight:	20kg	Power Supply:	220V, 50Hz
Warranty:	1 Year	Color:	Blue Or Grey
Highlight:	FMVSS 302 Flammability Tester , FMV SS302 , Interior Materials Flammability Tester

Introduction:

EC Directive 95/28/EC relates to the burning behavior of materials used in the interior construction of certain categories of motor vehicles, and is intended to ensure that they meet fire safety standards.

95/28/EC fire test to interior material of motor vehicle to determine the Characteristic of Burning: Horizontal Burning Behavior, Vertical Burning Behavior and Burning Dropping.

The Burn Resistance Tester can be used for determining the horizontal burning rate of motor vehicle materials.

Features:

FMV SS302 Burn Resistance Tester is suitable to determination for flammability, after burning, flame resistance and burning speed in car organic materials.
This Burn Resistance Tester complies with ISO 3795, ASTM D5132, FMVSS 302 etc.
Comprised of draft free stainless steel cabinet with observation window, sample holder and door mounted burner.
Automated control of timing and gas supply.

Specifications:

1	Application field	Automotive Interior
2	Reference standards	FMVSS: FMV SS302; ISO: ISO 3795; ASTM D5132
2	Dimension	430 mm (W) x 310 mm (D) x 360 mm (H)
3	Weight	20kg
4	Power supply	230 volts Nominal 10 Amps
5	Ambient temperature	Operating 25±5℃
6	Gas supply	Propane

FMV SS302 Flammability Burn Resistance Tester For Interior Materials 0
