Place of Origin: | China |
---|---|
Brand Name: | AI |
Certification: | ISO9001 |
Model Number: | BDV-2 |
Minimum Order Quantity: | 1 set Transformer Oil Breakdown Voltage Testing Equipment |
Price: | Negotiable |
Packaging Details: | Transformer Oil Breakdown Voltage Testing Equipment packed in veneer case |
Delivery Time: | 15 days |
Payment Terms: | Western Union, T/T, L/C, MoneyGram |
Supply Ability: | 100 sets each month |
Test Standards: | IEC156, IS6792, BS5874, ASTM D1816 , ASTM D877 | Test Voltage: | 80kV Or 100kV |
---|---|---|---|
Voltage Rise Rate: | 0.5kv/s± 5%, 2kv/s± 5%, 3kv/s± 5%, 5kv/s± 5% , , , | Keyword: | Transformer Oil Breakdown Voltage Testing Equipment, Insulating Oil Dielectric Strength Tester |
Resolution: | 0.1kV | Data Storage: | 100 Groups |
Size: | 550 Mm*500mm*580mm | Weight: | 38kg |
Power Supply: | 220V, 50Hz | Warranty: | 1 Year |
Highlight: | ASTM D877 Voltage Testing Equipment,Breakdown Voltage Testing Equipment,Transformer Oil Breakdown Voltage Tester |
Introduction:
Transformer Oil Breakdown Voltage Testing Equipment is developed according to IEC156 Insulating Oil Dielectric Strength Testing Method.
The oil test vessel with temperature measurement unit, so it can detect oil temperature.
Transformer Oil Breakdown Voltage Testing Equipment has 8 Kinds of test mode as optional: IEC156, IS6792, BS5874, ASTM D1816 , ASTM D877, Proof test, 5 minutes standard test, Manual test.
It has large LCD display, all the selection can be done by touch panel with color LCD.
Transformer Oil Breakdown Voltage Testing Equipment also has micro-printer and can store 100 groups data, test data can also be unload to PC and output word report automatically.
It is multi-functional, stable, and easy for operation;
Specifications:
1 | Output voltage | AC 0V~80KV |
2 | Rate of voltage rise | 0.5kv/s± 5%, 2kv/s± 5%, 3kv/s± 5%, 5kv/s± 5% |
3 | Max. test times | 9 |
4 | Stir time | 0~999s |
5 | Wait time | 0~999s |
6 | Measurement accuracy | ±(1% of full scale + 2 digits) |
7 | Resolution | 0.1KV |
8 | Temperature measurement range | 0°C to 70°C, or better |
9 | Temperature resolution | 1°C, or better |
10 | Data storage | 100 groups |
11 | Weight | 38kg |
12 | Size | 550 mm*500mm*580mm |
13 | Power supply | AC220V, 50Hz |
14 | Working environment | Room temperature to 45°C, humidity<85% |
