| Place of Origin: | China |
|---|---|
| Brand Name: | AI |
| Certification: | ISO |
| Model Number: | CST-II |
| Minimum Order Quantity: | 1 set Corrosive Sulfur Tester |
| Price: | Negotiable |
| Packaging Details: | Corrosive Sulfur Tester is packed in Hardboard |
| Delivery Time: | 30 days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 50 sets per month |
| Test Standards: | ASTM D1275,IEC 62535 | Temperature Range: | Ambient~150℃ |
|---|---|---|---|
| Temperature Controller: | Imported PID | Timing: | Digital Timer |
| Power Supply: | 220V 50HZ | Weight: | 31KG |
| Dimension: | 600×600×650mm³ | Total Power: | 1200W |
| Standard Copper Strip: | Purity 99.9%,thickness 0.125~0.250mm | Test Object: | Electrical Insulating Oils |
| Highlight: | Corrosive Sulfur Transformer Oil Test Set,IEC 62535 Corrosive Sulfur Analyzer,Digital Timer Corrosive Sulfur Analyzer |
||
Summary
1. The Corrosive Sulfur Tester has an air guide cooling system, when the surface temperature of the instrument is too high, it will automatically start to dissipate heat;
2. High-end enamel liner, corrosion-resistant and easy to clean;
3. The Corrosive Sulfur Tester is equipped with fan circulation and lighting device in the box;
4. The Corrosive Sulfur Tester uses imported Omron PID thermostat, digital display temperature, accuracy 0.1ºC
5. Over-temperature safety protection;
6. Innovative V-shaped door opening method, fully transparent high temperature resistant glass door;
7. The Corrosive Sulfur Tester adopts digital display timer, accuracy deviation per hour is not more than 2min, record test time, with time alarm.
Main specifications
| 1 | Reference standards | GB/T25961, ASTM D1275,IEC 62535 |
| 2 | Working temperature | Ambient~150ºC |
| 3 | Temperature controlling mode | Imported PID temperature controller |
| 4 | Timing method | Digital timer |
| 5 | Standard copper strip | Purity 99.9%,thickness 0.125~0.250mm |
| 6 | Total power | 1200W |
| 7 | Weight | 31KG |
| 8 | Dimension | 600×600×650mm³ |
| 9 | Power supply | AC 220V ,50Hz |
