20L 60L Asphalt Lab Equipment Bitumen And Bituminous Mixtures Blender

20L 60L Asphalt Lab Equipment Bitumen And Bituminous Mixtures Blender
20L 60L Asphalt Lab Equipment Bitumen And Bituminous Mixtures Blender 20L 60L Asphalt Lab Equipment Bitumen And Bituminous Mixtures Blender 20L 60L Asphalt Lab Equipment Bitumen And Bituminous Mixtures Blender 20L 60L Asphalt Lab Equipment Bitumen And Bituminous Mixtures Blender 20L 60L Asphalt Lab Equipment Bitumen And Bituminous Mixtures Blender 20L 60L Asphalt Lab Equipment Bitumen And Bituminous Mixtures Blender 20L 60L Asphalt Lab Equipment Bitumen And Bituminous Mixtures Blender 20L 60L Asphalt Lab Equipment Bitumen And Bituminous Mixtures Blender 20L 60L Asphalt Lab Equipment Bitumen And Bituminous Mixtures Blender 20L 60L Asphalt Lab Equipment Bitumen And Bituminous Mixtures Blender 20L 60L Asphalt Lab Equipment Bitumen And Bituminous Mixtures Blender 20L 60L Asphalt Lab Equipment Bitumen And Bituminous Mixtures Blender
Basic Information
Place of Origin: China
Brand Name: AI
Certification: ISO
Model Number: MB-20
Minimum Order Quantity: 1 PC Asphalt mxitures blender
Price: Negotiable
Packaging Details: Asphalt mxitures blender packed in Plywood case
Delivery Time: 20 days
Payment Terms: T/T, Western Union
Supply Ability: 1000 PC/Month
Get Best Price Contact Now
Capacity: 20L/60L Power Supply: AC(380±10%)V,50h
Temp.control Range: Room Temperature~200℃ Timing Range: (0~999) S
Weight: 210KG Size: 600mm×400mm×1300mm
Purpose: Determine The Rate Of Time(seconds) Of Liquid Flow Out From Engler Viscometer Warranty: 1 Year
Highlight:

20L Blender

,

60L blender

,

Asphalt mxitures blender

Bitumen And Bituminous Mixtures Blender

Summary
This asphalt blender is designed and made as per industrial standard T 0702-2011 Production Method for Test Specimen of Bituminous Mixture(Compaction method) in JTG E20-2011 Standard Test Methods of Bitumen and Bituminous Mixtures for Highway Engineering. It is used to blend the test specimen of bituminous mixtures before production.
The size of blender is small, space saving and easy to operate. It is a preferred instrument for blending the bituminous mixture for bitumen production companies, road and bridge building units, colleges and scientific research institutes.

I. Main technical features
1. This bituminous mixture blender adopts advanced microcomputer control technology. Temperature can be set from ambient to 200℃ at will and automatically adjusted by PID. The blending time can be controlled automatically. It achieves the automation for operation.
2. This blending machine has protecting function for phase sequence which can prevent the machine from damage because of phase sequence fault.
3. Floor type structure. Reasonable design and easy to use.

II. Main technical parameters and specifications
1 Blending amount 20L
2 Temperature control range Room temperature~200℃
3 Temperature control accuracy ±5℃
4 Timing range (0~999) s
5 Timing accuracy ±0.1s
6 Rotation rate of paddle Complete revolution 47R/min, Autorotation 76R/min
7 Lifting motor Alternating current 380V,250W；1400R/min；50Hz
8 Blending motor Alternating current 380V, 550W；1400R/min；50Hz
9 Overall dimension 600mm×400mm×1300mm
10 Net weight 215kg
11 Power supply AC(380±10%)V；16A；50Hz(three-phase four-wire with null line)
12 Ambient temperature (-5~+50)℃
13 Relative humidity Relative humidity

III.Package list

No.

Name Unit Qty
1 Automatic Mixture Blender Set 1
2 Discharge shovel Piece 1
3 Operation manual

Piece

1

20L 60L Asphalt Lab Equipment Bitumen And Bituminous Mixtures Blender 0

Tag:

Bitumen Testing Equipment,

asphalt testing machine,

Asphalt analysis
