Place of Origin: | China |
---|---|
Brand Name: | AI |
Certification: | ISO |
Model Number: | LWR |
Minimum Order Quantity: | 1 PC Load Wheel Rolling Tester |
Price: | Negotiable |
Packaging Details: | Load Wheel Rolling Tester packed in Plywood case |
Delivery Time: | 10 days |
Payment Terms: | T/T, Western Union |
Supply Ability: | 1000 PC/Month |
Rolling Frequency: | 44 Times / Min ± 1 Times / Min | The Crank Radius: | 152mm ± 2mm |
---|---|---|---|
Power Consumption: | 550W | Power Supply: | AC380V, 50Hz |
Size: | 1400mm × 260mm × 450 Mm | Warrnty: | 1 Year |
Purpose: | Controlling The Upper Limit Of The Amount Of Asphalt In The Slurry Mixture | Rubber Wheel Hardness: | Between HRC60 ~ HRC70 |
Highlight: | Load Wheel Rolling Tester,Slurry Mixture Tester,Sticky Sand Tester |
1 | Rolling frequency | 44 times / min ± 1 times / min |
2 | The crank radius | 152mm ± 2mm |
3 | Rubber wheel dimensions | diameter 76.5mm ± 1mm, width of 26.0mm ± 1.0mm |
4 | Rubber wheel hardness | Between HRC60 ~ HRC70 |
5 | Rubber wheel loading weight | total weight of the car lay flat 56.7kg ± 0.5 kg; |
6 | Test mode | There are 6.4mm, 12.7mm thickness of two kinds, according to the need to use the internal dimensions of 50mm × 380mm |
7 | Sand frame | internal dimensions of length 355.0 mm × width 38.0 mm × thickness 0.5 mm |
8 | Steel plate | dimensions of length 353 mm × width 36 mm × height 3 mm |
9 | Dimensions | 1400mm × 260mm × 450 mm (length × width × height) |
10 | Power Supply | AC380V, 50Hz, 550W (three-phase four-wire system, with zero line). |
No. | Name | Unit | Qty | Memo |
1 | Load Wheel Rolling Tester | Set | 1 | |
2 | Test mode baseplate | Block | 1 | Stainless steel,installed at the bottom of seat |
3 | Test mode,thickness 6.4mm,12.7mm | Piece | Each 1 | Plastic parts |
4 | Sand frame(the bottom posted with rubber sand frame) | Piece | 1 | Metal sand frame,installed at bottom |
5 | Steel desk-plate | Piece | 1 | |
6 | Rubber sand frame(Posted with 3 M double side tape) | Piece | 1 | |
7 | Fuse 10A(Ф6×30) | Piece | 2 | |
8 | Butterfly nut | Piece | 8 | |
9 | Tall Pressing plate | Piece | 8 | |
10 | Support wooden bracket | Block | 1 | Placed under the machine to hang the rubber wheel in the air |
11 | Operation manual | Piece | 1 |
