Advanced Instruments Co.,Limited
To Be Advanced in Quality and Service!
| Place of Origin: | China |
|---|---|
| Brand Name: | AI |
| Certification: | ISO |
| Model Number: | SVT |
| Minimum Order Quantity: | 1 PC Asphalt Saybolt Viscometer |
| Price: | Negotiable |
| Packaging Details: | Asphalt Saybolt Viscometer packed in Plywood case |
| Delivery Time: | 15 days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 1000 PC/Month |
| Test Method: | Saybolt Viscometer Method | Test Standard: | ASTM D88 |
|---|---|---|---|
| Power Supply: | AC(220±10%)V 50Hz | Working Temp.: | Room Temp.~240℃ |
| Size: | 360mm×360mm×790mm | Working Position: | 2 Units |
| Timing Range: | 0.0s~999.9s | Receiving Flask: | (60±0.0)5ml |
| Highlight: | asphalt lab equipmeSaybolt Viscosity Test Apparatusnt,Saybolt Viscometer,ASTM D88 |
||
I.Introduction:
The saybolt viscometer is designed and made as per T 0623 Bitumen Saybolt Viscosity Test (Saybolt Viscometer Method) in the JTG E20-2011 Standard Test Methods for Bitumen and Bituminous Mixtures for Highway Engineering.
It is suitable to determine the Saybolt viscosity of bitumen and bituminous mixtures under a constant temperature as per T0623.
II.Features:
1. This saybolt viscosity tester is composed of bath, temperature controller, parameters display and calculation (calibration coefficient, time, viscosity and so on).
2. This bitumen saybolt viscosity testing equipment adopts micro computer technology. It equips double lines to detect. It can determine two samples at the same time. It can display the parameters and calculate the arithmetic mean value automatically.
3. This saybolt viscosity apparatus can convert the Saybolt viscosity to Engler viscosity and kinematic viscosity automatically. Operator can get three viscosity data from one test. The work efficiency is high.
III.Specifications:
| 1 | Power supply | AC(220±10%)V 50Hz |
| 2 | Instrument structure | Desktop type |
| 3 | Working mode | Double lines,parallel test |
| 4 | Receiving flask | (60±0.0)5ml |
| 5 | Heating power of bath | 1000W |
| 6 | Working temperature of bath | Room temp.~240℃ |
| 7 | Temperature control accuracy | ±0.1℃ |
| 9 | Timing range | 0.0s~999.9s |
| 9 | Timing accuracy | ±0.1s |
| 10 | Ambient temperature | ≤35℃ |
| 11 | Relative humidity | ≤85% |
| 12 | Overall dimension | 360mm×360mm×790mm |
III.Accessories List
| No. | Item | Unit | Qty |
| 1 | Sample receiving flask | Piece | 2 |
| 2 | Stopper handle | Piece | 2 |
| 3 | Stopper | Piece | 10 |
| 4 | Mercury thermometer 0～50 ℃, scale division is 0.1 ℃ | Piece | 1 |
| 5 | Mercury thermometer 0～300 ℃, scale division is 1 ℃ | Piece | 1 |
| 6 | Stopper for glass thermometer (silicon gel stopper 8 #) | Piece | 1 |
| 7 | Stopping ring for thermometer (1#) | Piece | 4 |
