Bare Wire Bend And Reverse Bend Tester For Specimen Length Of 300mm

Bare Wire Bend And Reverse Bend Tester For Specimen Length Of 300mm
Bare Wire Bend And Reverse Bend Tester For Specimen Length Of 300mm Bare Wire Bend And Reverse Bend Tester For Specimen Length Of 300mm Bare Wire Bend And Reverse Bend Tester For Specimen Length Of 300mm Bare Wire Bend And Reverse Bend Tester For Specimen Length Of 300mm Bare Wire Bend And Reverse Bend Tester For Specimen Length Of 300mm Bare Wire Bend And Reverse Bend Tester For Specimen Length Of 300mm Bare Wire Bend And Reverse Bend Tester For Specimen Length Of 300mm Bare Wire Bend And Reverse Bend Tester For Specimen Length Of 300mm Bare Wire Bend And Reverse Bend Tester For Specimen Length Of 300mm
Basic Information
Place of Origin: China
Brand Name: AI
Certification: ISO
Model Number: AIC22180
Minimum Order Quantity: 1 set Bend and Reverse Bend Tester
Price: Negotiable
Packaging Details: Bend and Reverse Bend Tester is packed in Plywood case
Delivery Time: 30 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 200 sets per month
Get Best Price Contact Now
Specimen Length: 300mm Suitable Wire OD: φ0.7mm ~ φ8.0mm
Bending Rate: 10 To 60 Beats / Min Times Setting: 0 To 9999 Times
Cylindrical Bending Radius: R2.5, R3.75, R5, R7.5, R10, R15, R20mm Distance: 15 ~ 100mm, Adjustable
Dimension: 700mm×450mm×1000mm Power Supply: AC 220V 50 / 60Hz 0.75kW
Color: White Warranty: One Year
Highlight:

Bare Wires Bend Tester

,

Cable Reverse Bend Tester

,

Bend and Reverse Bend Tester

Product description:
Bare wire bend and reverse bend tester is applicable to production plants and users of wires and cables, bare wires, wire ropes and others. Mainly use for repeated bending tests of bare wires and metal wires, to detect their plastic deformation performance and failures in repeated bending.
Test method: fix one end of the specimen, and the free end along with a predetermined radius of cylindrical surface to do bending test at 90° normal and reverse directions.

Standards:
• GB / T4909.5-2009

Technical parameters:
• Specimen length: 300mm
• Suitable wire OD: φ0.7mm ~ φ8.0mm
• Bending rate: 10 to 60 beats / min
• Times setting: 0 to 9999 times, settable
• Cylindrical bending radius: r2.5, r3.75, r5, r7.5, r10, r15, r20mm
• Distance: 15 ~ 100mm, adjustable

Specifications:
• Overall dimensions: 700mm×450mm×1000mm
• Power supply: AC 220V 50 / 60Hz 0.75kW
