IEC60851-3 Automated Springiness Test Instrument For Copper Wires

IEC60851-3 Automated Springiness Test Instrument For Copper Wires
IEC60851-3 Automated Springiness Test Instrument For Copper Wires IEC60851-3 Automated Springiness Test Instrument For Copper Wires IEC60851-3 Automated Springiness Test Instrument For Copper Wires IEC60851-3 Automated Springiness Test Instrument For Copper Wires IEC60851-3 Automated Springiness Test Instrument For Copper Wires IEC60851-3 Automated Springiness Test Instrument For Copper Wires IEC60851-3 Automated Springiness Test Instrument For Copper Wires IEC60851-3 Automated Springiness Test Instrument For Copper Wires IEC60851-3 Automated Springiness Test Instrument For Copper Wires
Basic Information
Place of Origin: CHINA
Brand Name: AI
Certification: ISO
Model Number: AIHTJ-16
Minimum Order Quantity: 1 Set Springiness Test Instrument
Price: Negotiable
Packaging Details: Springiness Test Instrument is packed in plywood case
Delivery Time: 15 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100 sets per month
Get Best Price Contact Now
Test Standard: IEC60851-3 Winding And Rebound Speed: 7±0.5 R /min
Power Supply: AC220V±10% 50Hz Power Consumption: <80W
Dimension: 560×314×360mm Weight: 25KG
Color: Blue Language: English
Highlight:

Springiness Test Instrument

,

Springiness Test Kit

,

IEC60851-3 Springiness Test

Performance Characteristics
1.Executive standard: GB/T4074.3-2008,IEC60851-3; Inspection standard: JB/T4279.4-2008
2.This Springiness Test Instrument is used to measure the rebound resistance of enameled round wires with nominal conductor diameter of between 0.080mm and 1.600mm;
3.This Springiness Test Instrument adopts SCM control for fast operation and strong anti-interference capacity;
4.Automatic stop after winding 5 circles;
5.Sensor is unnecessary to be adjusted for samples of different specifications;
6.Coils slowly loosen during springiness, free from abrupt springiness or bounce.
7.LED automatically records and displays test results;
8.Error between displayed value and indicating value on dial is no more than ±1°;
9.Simple operation, high sensitivity and excellent repeatability.

Technical Parameters

Winding and rebound speed of sample 7±0.5 r /min
Input power AC220V±10%,50Hz
Power consumption <80W
Overall dimensions L×W×H 560×314×360mm
Weight 25kg


Preparation of weight: Unit: N

Load 0.25 0.50 1.0 2.0 4.0 8.0 12.0 15.0
Error ± 0.02 0.05 0.1 0.2 0.4 0.8 1.0 1.0


Preparation of test bar: Unit: mm

Diameter of test bar 5 7 10 12.5 19 25 37.5 50
Error ± 0.16 0.18 0.18 0.22 0.26 0.26 0.32 0.32
