NPFA 701 Flame Propagation Test Equipment for Textiles and Films

Basic Information

Place of Origin:	China
Brand Name:	AI
Certification:	ISO9001
Model Number:	NPF-2

Minimum Order Quantity:	1 set
Price:	Negotiable
Packaging Details:	It is packed in veneer case.
Delivery Time:	10-20 days
Payment Terms:	Western Union, T/T, L/C
Supply Ability:	100 sets each month

Get Best Price Contact Now

Reference Standards:	NPFA 701	Application Field:	Textiles And Films
Gas Supply:	Methane	Dimension:	350mm (W) X 2050mm X (H) X 350mm (D)
Weight:	51kg	Power Supply:	220V, 50Hz
Warranty:	1 Year	Color:	Grey
Highlight:	NPFA 701 , Flame Propagation Test Equipment , Textiles test equipment

Introduction:

NFPA 701 is Standard Methods of Fire Tests for Flame Propagation of Textiles and Films.

According to different fabric weight, divided into 1 methods and methods 2.

Features:

Specified apparatus for all hanging decorative materials weighing not less than 21 oz/yd² (700 g/m²).
Stainless steel test cabinet with glass observation panel.
25° angle Bunsen burner with automatic timer to preset ignition time and record afterflame.
Gas system include the flow meter, pressure meter and pressure reducing valve.
Specimen holder included.

Specifications:

1	Application field	Upholstered Furniture
2	Reference standards	NFPA 701
2	Dimension	350mm (W) x 2050mm x (H) x 350mm (D)
3	Weight	51kg
4	Power supply	230 volts Nominal 10 Amps
5	Ambient temperature	Operating 25±5℃
6	Gas supply	Methane
