SF6 Dew Point Tester for SF6 Moisture Content Testing Equipment

Basic Information

Place of Origin:	China
Brand Name:	AI
Certification:	ISO9001
Model Number:	DPT

Minimum Order Quantity:	One set SF6 Moisture Content Testing Equipment
Price:	Negotiable
Packaging Details:	SF6 Moisture Content Testing Equipment packed in veneer case.
Delivery Time:	20 days
Payment Terms:	Western Union, T/T, L/C
Supply Ability:	100 sets each month

Get Best Price Contact Now

Dew Point Measurement Range:	－80℃～+20℃	Moisture Content Measurement Range:	0～19999ppm
Sampling Flow Rate:	0.6L/min±20%	Charging Time:	4 Hours
Dimension:	25cm15cm30cm	Weight:	3.5kg
Color:	White	Warranty:	1 Year
Highlight:	SF6 Dew Point Tester , Dew Point Tester , SF6 Moisture Tester

Introduction:

SF6 Moisture Content Testing Equipment adopts imported high-precision dew point sensor and the latest digital circuit control technology, it is the intelligent and precision instrument to measure moisture content in SF6 gas.
uses intelligent self-calibration technology, with wide measuring range, fast response, high accuracy, good linearity, dynamic display measurement curv
SF6 Moisture Content Testing Equipment is also with automatic dryer, can greatly shorten the measuring time.

Specifications:

1	Measurement Range	Dew point value	－80℃～+20℃
		Micro water value	0～19999ppm
2	Accuracy	±0.5℃(-60℃～+20℃)
		±1.0℃(-80℃～-60℃)
3	Resolution	Dew point value	0.1℃
		Micro water value	1uL/L
4	Response time (+20℃,0.1Mpa)	63% need 5s, 90% need 45s (-60 ℃ ~ +20 ℃)
		63% need 10s, 90% need 240s (+20 ℃ ~ -60 ℃)
5	Sampling flow rate	0.6L/min±20%
6	Pressure range	0～1.0Mpa
7	Temperature	－20℃～＋60℃
8	Humidity	0～100%RH
9	Storage Temperature	－20℃～＋80℃
10	Charging time	4 hours
11	Dimension	25cm15cm30cm
12	Weight	3.5kg

Features:

High stability: Under severe interference conditions, the measurement data can be stabilized within ± 0.5 ℃, with excellent long-term stability, good repeatability.
High precision: Adopts imported with original packaging high-performance dew point sensor and high-speed 12 Σ-ΔAD analog-to-digital converter (ADC), the highest resolution reaches 0.1 ℃, fully meet the requirements of the actual measurement. The measurement results are accurate and reliable within full range. Wide measuring range, fast response, stable and reliable.
Intellectualized: Boot self-calibration, the sensor probe can be automatically calibrated zero, automatically eliminate systematic errors introduced by zero drift, to ensure the accuracy of measurement.
Multiple protections: With oil filters, not affected by dust particles and most of chemical contamination, to protect sensor resistance to oil, very suitable for use in industrial environments. Dryer can effectively protect the dew point sensor probe, prolong the service life of the sensor.
Rapid to save gas: after boot into measurement, the measurement time of dew point is 3 ~ 5min. First use need to dry pipelines and sensors, slightly longer time.
Powerful function: 4.7 inch colors touching LCD display. Direct display dew point value (℃), micro-water value (uL / L), date and time, dynamic display dew point measuring curve. Real-time save measurement data, can store up to 100 sets of measurement data.
Communication: RS232 interface can be connected to PC serial port, convenient for further process data.
Easy to use: Adopts imported self-locking connectors, easy to plug in or draw out, safe and reliable, no leakage. Touching buttons easy to operate and improve work efficiency. Built-in rechargeable lithium battery, small in size, light in weight, easy to carry.
