| Place of Origin: | China |
|---|---|
| Brand Name: | AI |
| Certification: | ISO9001 |
| Model Number: | RRT |
| Minimum Order Quantity: | 1 set Thermal Radiation Test Equipment |
| Price: | negotiable |
| Packaging Details: | Thermal Radiation Test Equipment packed in plywood case |
| Delivery Time: | 60 days |
| Payment Terms: | Western Union, T/T, L/C |
| Supply Ability: | 20 sets each month |
| Test Standard: | EN 136 | Test Object: | Full Face Mask |
|---|---|---|---|
| Power Supply: | 220V,30A | Dimension: | 1,240(W)X700mm(D)X1,600(H)mm |
| Weight: | 152KG | Color: | Black Or White |
| Warranty: | 1 Year | Main Heater Power: | 4000W |
| Highlight: | Thermal Radiation Test Equipment,EN 136,Full Face Masks Test Equipment |
||
Product introduction
The Full Face Mask Thermal Radiation Test Equipment is suitable for testing the radiation resistance of full face mask respiratory protective devices in EN136 standard. Its purpose is to detect whether the mask will cause protection failure after being exposed to the standard heat radiation source after the standard test time.
Full face masks for diving apparatuses are not included in the scope of this standard.
Performance characteristics
1. The Full Face Mask Thermal Radiation Test Equipment is equipped with electric heating tube heating device, the main heater power is 4000W, the auxiliary heater power is 2000 W, which is regulated by two PID temperature controllers.
2. Stainless steel reflector used to enhance the thermal radiation performance applied on the mask;
3. The Full Face Mask Thermal Radiation Test Equipment has metal head mould device, which can wear face mask and breathe freely;
4. The sliding track of the metal head mould can move its horizontal position and adjust the distance from the mask to the radiator.
5. The Full Face Mask Thermal Radiation Test Equipment is provided with a water-cooled heat flow meter for measuring the heat radiation flux at the standard distance;
6. The test equipment adopts artificial lung breathing device, breathing is a sinusoidal output mode, which truly simulates human breathing.
7. PLC control mode, breathing frequency and breathing volume can be set freely.
8. Micro-differential pressure sensor device, which can automatically detect the failure of the mask in the process of testing.
Installation requirements
| 1 | Power supply | 220V,30A |
| 2 | Dimension | 1,240(W)X700mm(D)X1,600(H)mm |
| 3 | Weight | 152KG |
| 4 | Test object | Full face mask |
| 5 | Test standard | EN 136,GB/T 16556 |
