Place of Origin: | China |
---|---|
Brand Name: | AI |
Certification: | ISO |
Model Number: | VW-N |
Minimum Order Quantity: | 1 Set VW-1 Vertical Rating Flame Test Chamber |
Price: | Negotiable |
Packaging Details: | 1 Set VW-1 Vertical Rating Flame Test Chamber packed in Plywood case |
Delivery Time: | 45 days |
Payment Terms: | D/P, T/T, L/C, Western Union |
Supply Ability: | 10 Sets per Month |
Test Standard: | UL 1581 VW-1,ASTM D5025,ASTM D5207 | Purpose: | Measures The Resistance Of Insulating Materials To The Propagation Of A Fire |
---|---|---|---|
Test Chamber Size: | 2.1M (L) *1.2M (W) *1.8M (H) | Control Chamber Size: | 0.4m (L) *0.3m (W) *1.2m (H) |
Display: | Touch Screen LCD | Color: | White And Black |
Other Name: | VW-1 Vertical Flame Test Chamber | Warranty: | 1 Year |
Highlight: | VW-1 Flame Chamber,Flame Test Chamber,Fire Rating Test |
Introduction
This vertical fire rating test equipment (VW-1) is designed according to UL2556 9.4 FV-2/VW-1, ;to assess the flame spreading ability to combustible near by of cable or flexible wire when it caught fire.The whole test is carried out in a sealed test chamber with a volume of 4.54m³.
Main advantages
1, The vertical flame test chamber is electrolytic plate electrostatic spraying, elegant appearance, and inside is roasted black;
2, The fire rating test equipment is equipped with powerful exhaust fume extractor on the top, and open it when the test is completed, to air the exhaust automatically;during the test, this extractor is closed.;
3, The glass viewing window is on the front box, allowing easy observation during the test;
4, The vertical flame test chamber is equipped with sealed glove to operate the burner inside.
5, Test chamber size: 2.1M (L) *1.2M (W) *1.8M (H),The control chamber size:0.4m (L) *0.3m (W) *1.2m (H),And available space: 4.4m3.
Control system
• PLC with touch screen smart control systems implement test process automation.
• Customers free to set test time;
• An experimental system automatically calculates and stores the test data.
• Burning settings: 0-999.99 seconds to set freely;
• To stop burning set: 0-999.99 seconds to set freely;
• Burning count: 0-999 seconds to set freely.
Basic information
1 | Power supply | AC220V 50/60Hz, 1A |
2 | Gas source | methane |
3 | Dimension | 2150mm x 1200mm x 2150mm |
Picture of VW-1 Vertical Wire Fire Rating Test System with Diluxe Configuration
