Place of Origin: | China |
---|---|
Brand Name: | AI |
Certification: | ISO |
Model Number: | PCI-2 |
Minimum Order Quantity: | 1 Set Primary Current Injection Test Kit |
Price: | Negotiable |
Packaging Details: | Primary Current Injection Test Kit packed in Plywood case |
Delivery Time: | 15 days |
Payment Terms: | T/T, Western Union, L/C |
Supply Ability: | 100 sets per month |
Power Supply: | AC220V±10%, 50Hz/60Hz | Display: | Digital |
---|---|---|---|
Capacity: | 3KVA-15KVA | Current Range: | 500A-25KVA |
Keyword: | Primary Current Injection Test Kit | Warranty: | 1 Year |
Working Condition: | 0-50℃, ≤85%RH | Structure: | Separated Or Integrated |
High Light: | Primary Current Injection Test Kit,Primary Injection Test Kit,High Current Generator |
High Current Generator Primary Current Injection Tester Kit
I. Introduction:
Primary current injection tester is an essential equipment used for electrical debugging to generate high current, which be widely used in power plants, power distribution stations, electrical plants , scientific research, laboratories and other units.
Primary cuurent injection test kit is a short-term or intermittent work device and characterized by small size, light weight, good performance, easy use and maintenance.
Features:
1. Two ammeters can supervise different measurement range.
2. With indicator lighting and button, this high current generator is easy to operate
3. This primary injection kit adopts integrated and separted structure, easy to move.
4. The primary current injection test set capacity is designed based on 5-minute short-term work system. For intermittent work, working time should be less than 2.5 minutes, before continuing to work it should be shut down for 10 minutes so that all parts of the machine can cool down.
III. Specifications:
Model | Capacity (kVA) |
Junior Range |
Secondary Range |
Dimensions (mm) L×W×H |
Weight ( kg) |
Structure | ||
V1 | A1 | V2 | A2 | |||||
PCI-3/500 | 3 | 220 | 15 | 6 | 500 | 430×338×550 | 45 | Integrated |
PCI-6/1000 | 6 | 220 | 27 | 6 | 1000 | 500×380×600 | 65 | Integrated |
PCI-12/2000 | 12 | 380 | 31.6 | 6 | 2000 | 580×400×750 | 105 | Integrated |
PCI-15/2500 | 15 | 380 | 39.5 | 6 | 2500 | 600×430×790 | 145 | Integrated |
PCI-24/4000 | 24 | 380 | 63 | 6 | 4000 | 640×450×820 | 180 | Separated |
PCI-30/5000 | 30 | 380 | 79 | 6 | 5000 |
600×430×900 300×500×500 |
145 135 |
Separated |
PCI-36/6000 | 36 | 380 | 95 | 6 | 6000 |
600×430×900 300×500×500 |
150 140 |
Separated |
PCI-48/8000 | 48 | 380 | 126 | 6 | 8000 |
600×450×950 350×550×550 |
180 | Separated |
PCI-60/10000 | 60 | 380 | 158 | 6 | 10000 |
800×600×1100 380×550×600 |
200 | Separated |
Working environment | 0-50℃, ≤85%RH | |||||||
The capacity and maximum current output could be customized according to the requirements of customer if you can not find the one you need in this table. |
