ASTM D566 Oil Bath Dropping Point Tester of Lubricating Grease

ASTM D566 Oil Bath Dropping Point Tester of Lubricating Grease
ASTM D566 Oil Bath Dropping Point Tester of Lubricating Grease ASTM D566 Oil Bath Dropping Point Tester of Lubricating Grease ASTM D566 Oil Bath Dropping Point Tester of Lubricating Grease ASTM D566 Oil Bath Dropping Point Tester of Lubricating Grease ASTM D566 Oil Bath Dropping Point Tester of Lubricating Grease ASTM D566 Oil Bath Dropping Point Tester of Lubricating Grease ASTM D566 Oil Bath Dropping Point Tester of Lubricating Grease ASTM D566 Oil Bath Dropping Point Tester of Lubricating Grease ASTM D566 Oil Bath Dropping Point Tester of Lubricating Grease ASTM D566 Oil Bath Dropping Point Tester of Lubricating Grease ASTM D566 Oil Bath Dropping Point Tester of Lubricating Grease ASTM D566 Oil Bath Dropping Point Tester of Lubricating Grease
Basic Information
Place of Origin: China
Brand Name: Advanced Instruments
Certification: ASTM D566
Model Number: SCT-III
Minimum Order Quantity: 1 set
Price: US$500-1000/set
Packaging Details: Plywood Case
Delivery Time: 20days
Payment Terms: T/T, L/C, D/P
Supply Ability: 50Sets Per Month
Get Best Price Contact Now
Test Standard: ASTM D566 Warranty: 1full Year
Transport Package: Plywood Case Trandmark: Advanced Instruments
Operating Power Supply: AC220 V±10V, 50Hz Total Power Consumption: ≤900W
Oil Bath: 600ml Beaker Stirring Motor: 60R / Min
Temperature Display: (15~35)℃ Relative Humidity: ≤85%
Thermometer: (-5~300) ℃ Net Weight: 8kg
Highlight:

ASTM D566

,

Grease Dropping Point Tester

,

Oil Bath Drip Point Analyzer

General Introduction



This Dropping Point Tester of Lubricating Grease is designed and made as per the national standard of People's Republic of China GB/T 4929 Lubricating grease- Determination of Dropping Point and ASTM D566 Standard Test Method for Dropping Point of Lubricating Grease.



Product Advantages



1.The oil bath is formed by high-temperature resistant beaker, heater and electric stirrer, and the heating power is continuously adjustable.

2.The Grease Dropping Point Analyzer is equipped with two sets of test tube holes, which can test two sets of specimens at the same time to improve work efficiency.

3.This Grease Dropping Point Testing instrument structure is reasonably designed, beautiful in shape and environmentally friendly.

ASTM D566 Oil Bath Dropping Point Tester of Lubricating Grease 0


The Technical Specifications and Parameters



Power supply AC(220±10%)V, 50Hz
Total power consumption 900W
Oil Bath 600ml Beaker
Grease Cup made of chrome plated brass,
Inner diameter: 9.92mm,
Oil dripping hole: 2.8mm,
Cup height: 12mm
Test Tube Heat resistant borosilicate glass tube with edge,
Inner diameter: 11.1 mm to 12.7 mm, with three grooves to support the fat cup on the circumference 19mm from the bottom
Thermometer Temperature range: (- 5~300) ℃;
Division value: 1 ℃
Stirring motor 60R / min
Working environment Temperature:(15~35)℃; Relative humidity:≤85%
Net Weight 8KG
Dimension 350mm×180mm×410mm


ASTM D566 Oil Bath Dropping Point Tester of Lubricating Grease 1


FAQ
1.What's the delivery time?
About 20days.
2.What's your payment terms?
30% paid by T/T in advance,70% paid by by T/T before shipping.
3.What's your guarantee terms?
The warranty of all products is 1 year.During this period,we are responsible for all faults caused by us.And we can supply life-long technical support.
4.Can you supply training?
We can supply training in our factory and online training for free.If onsite installation and training are required,please pay for tickets,accommodation and salary USD280/Day for every person.
