ASTM D2602 Auto-sampling CCS Apparent Viscosity Apparatus Cold Cranking Simulator

Basic Information

Place of Origin:	China
Brand Name:	AI
Certification:	ISO
Model Number:	CCS-III

Minimum Order Quantity:	1 set CCS Apparent Viscosity Apparatus
Price:	Negotiable
Packaging Details:	CCS Apparent Viscosity Apparatus packed in Hardboard
Delivery Time:	30 days
Payment Terms:	L/C, T/T, Western Union, MoneyGram
Supply Ability:	200 sets per month

Get Best Price Contact Now

Standards:	GB/T6538, ASTM D2602,ASTM D5293	Test Method:	Cold-Cranking Simulator
Temperature Controlling Range:	-5℃~-35℃	Display:	LCD
Power Supply:	AC220V, 50Hz	Measuring Range:	1500~15000CP
Warranty:	1 Year	Sampling:	Automatic
Cooling Method:	Semi-conductor	Control:	PC
Highlight:	ASTM D5293 CCS Test Apparatus , Apparent Viscosity Test Instrument , Cold Cranking Simulator Analyzer

ASTM D2602 Auto-sampling CCS Apparent Viscosity Apparatus Cold Cranking Simulator 0

Introduction:

Cold Cranking Simulator Apparatus is used to measure the apparent viscosity of engine oil at low temperature (- 35 ºC ~ - 5 ºC). Method summary: Drive a rotor closely matched with the stator by a DC motor, and fill the gap between the rotor and the stator with samples.
The temperature is controlled by the temperature control system, and the motor speed is corrected with standard oil to make it a function of viscosity. Determine the sample viscosity by measuring the rotation speed. The rotor and stator system of the Cold Cranking Simulator uses a thermoelectric temperature control system. Compared with the previous model, the temperature control is improved, the preheating time is reduced, and the measurement accuracy is improved. The compact structure is easy to install and use.

Features:

1.The CCS test machine can automatically detect rotation speed,control current,and reduce error;
2.Refrigerated by semi-conductor;
3.The Cold Cranking Simulator adopts imported motor,accuracy is high;
4.LCD displays all working status;
5.It can connect printer to print out result;
6.Result can be calculated automatically after calibrating with standard oil;
7.Micro-computer controlling,Windows operation system,complete English interface;
8.Upgraded rotor,low rotor torque test status,high repeatability;
9.Automatically generate calibration curve,directly display measured result of viscosity;
10.All test procedures are controlled automatically,when test is over,it can stop and raise temperature automatically.
11.The instrument recommends refrigeration temperature automatically
12.Rotary encoder detects rotation speed;
13.Measuring range:1500~15000CP;
14.It can edit 10 types standard oil results;
15.This apparent viscosty tester is equipped with low temperature cooling device.

Specifications:

1	Reference standard	GB/T6538, ASTM D2602,ASTM D5293
2	Refrigeration method	Semi-conductor
3	Circulation method	multifunctional plastic steel pump
4	Temp.controlling method	Digital PID temperature controller
5	Detection method	Automatic test
6	Data processing	Automatic store and print
7	Temp.controlling range	Ambient~-35ºC
8	Power supply	AC220 V 50Hz
9	Test tubes	16 positions

ASTM D2602 Auto-sampling CCS Apparent Viscosity Apparatus Cold Cranking Simulator 1
