DIN 51568 Lubricating Oils Flow Ability Test Instrument By U-Tube Method

DIN 51568 Lubricating Oils Flow Ability Test Instrument By U-Tube Method
DIN 51568 Lubricating Oils Flow Ability Test Instrument By U-Tube Method DIN 51568 Lubricating Oils Flow Ability Test Instrument By U-Tube Method DIN 51568 Lubricating Oils Flow Ability Test Instrument By U-Tube Method DIN 51568 Lubricating Oils Flow Ability Test Instrument By U-Tube Method DIN 51568 Lubricating Oils Flow Ability Test Instrument By U-Tube Method DIN 51568 Lubricating Oils Flow Ability Test Instrument By U-Tube Method DIN 51568 Lubricating Oils Flow Ability Test Instrument By U-Tube Method DIN 51568 Lubricating Oils Flow Ability Test Instrument By U-Tube Method DIN 51568 Lubricating Oils Flow Ability Test Instrument By U-Tube Method
Basic Information
Place of Origin: China
Brand Name: AI
Certification: ISO
Model Number: AIC-51568
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Hardboard
Delivery Time: 30 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 20 sets per month
Get Best Price Contact Now
Test Standard: DIN 51568 Power Supply: AC220V,50HZ
Temperature Control Range: RT~60ºC Cooling Method: Double Compressor
Total Power Consumption: ≤1000W Working Position: 2 Units
Language: English Pressure Range: 980±10PA
Temperature Controller: Omron Color: Grey
Highlight:

Flow Ability Instrument

,

DIN 51568 Lubricating Oils Test Instrument

,

Flow Ability Test

Summary
This Flow Ability Test Instrument is applicable to determine ability to flow of lubricating oil.
The operating principle is to measure the rising speed of lubricating oil in the U-shaped pipe under constant pressure and specified low temperature conditions, which is expressed by the temperature when the rising speed under such conditions is 10mm/min.


I. Main technical features
1. The Flow Ability Test Instrument adopts Double compressor cascade refrigeration ensures the supply of cooling capacity;
2. Microcomputer temperature controller, digital display, accuracy ± 0.2 ºC PT100 sensor;
3. Glass Dewar bottle for cold bath, good heat preservation effect;
4. Split structure to reduce the damage caused by instrument vibration;
5. The Flow Ability Test Instrument provides Stainless steel heater;
6. Evaporator adopts copper chrome plated coil;
7. The back of the Dewar bottle is provided with sunlight for easy observation;
8. Stainless steel clamping system can quickly clamp the test tube;
9. Special glass test tube, meeting the standard requirements;
10. The Flow Ability Test Instrument display pressure digitally.

II. Main technical specifications
1 Power supply AC(220±10%)V, 50Hz
2 Applicable standard DIN 51568, GB/T12578
3 Cooling method Double compressor
4 Temperature range RT~60ºC
5 Temperature controlling Digital PID
6 Total power 1KW
7 Pressure range 980±10PA
