Place of Origin: | China |
---|---|
Brand Name: | AI |
Certification: | ISO |
Model Number: | AIC-3527 |
Minimum Order Quantity: | 1 set ASTM D3527 Life Performance Tester |
Price: | Negotiable |
Packaging Details: | ASTM D3527 Life Performance Tester packed in hardboard box |
Delivery Time: | 30 days |
Payment Terms: | L/C, T/T, Western Union |
Supply Ability: | 100 sets per month |
Test Standard: | ASTM D3527,SH/T0773 | Power Supply: | AC220V,50HZ |
---|---|---|---|
Total Power: | 1.5KW | Load: | 111N |
Temperature Control Range: | Ambient~300℃ | Rotating Speed: | 3000r/min |
Time Control: | Digital Timer | Warranty: | 1 Year |
Highlight: | ASTM D3527 Life Performance Tester,111N Load Life Performance Tester,3000r/Min Life Performance Tester |
ASTM D3527 Life Performance Tester For Automotive Wheel Bearing Grease
Introduction
ASTM D3527 Life Performance Tester adopts computer fully automatic control and automatically judges the results. After the sample is installed, the tester automatically performs intermittent work according to the standard requirements, and the entire process does not need to be maintained manually, which greatly reduces the operating intensity. In order to avoid safety accidents, the new generation of products has a fault reminder in the program, automatic shutdown of the instrument failure, to ensure the use of equipment or other hardware.
Characteristic
1. The Life Performance Tester adopts High-speed DC motor 3000r/min;
2. Digital meter displays the motor speed, adjustable, and is equipped with an overload protection device;
3. The test bearing meets the requirements of the standard;
4. Heat insulation materials are used in the heating box for heat preservation;
5. Fixed loading devices without deviation;
6. Microcomputer temperature controller, digital display, accuracy ±1℃ PT100 sensor;
7. Digital display timer to record test time;
8. There is a hole for inserting a thermometer on the bearing sleeve;
9. Life Performance Tester has long-life dry-burning electric heater, stainless steel cabinet, easy to clean;
10. Windows operating system, Chinese interface;
11. The test bearing tooling is easy to disassemble and easy to operate;
12. The system automatically detects faults and shuts down;
13. The test data automatically generates a curve and displays it in digital form;
14. The test results are automatically stored and can be queried
Technical specifications
1 | Applicable standards | SH/T0773,ASTM D3527 |
2 | Temperature control method | Digital PID |
3 | Timing method | Digital timing |
4 | Temperature control range | Ambient~300℃,±1℃ |
5 | Load | 111N |
6 | Total power | 1.5KW |
7 | Power supply | AC220V,50HZ |
