| Place of Origin: | China |
|---|---|
| Brand Name: | AI |
| Certification: | ISO |
| Model Number: | AIC-4049 |
| Minimum Order Quantity: | 1 set Resistance to Water Spray Test Equipment |
| Price: | Negotiable |
| Packaging Details: | Resistance to Water Spray Test Equipment packed in Hardboard |
| Delivery Time: | 30 days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 20 sets per month |
| Test Standard: | ASTM D4049 | Power Supply: | AC220V,50HZ |
|---|---|---|---|
| Timing Method: | Digital Timer | Working Temperature: | 38±0.2℃ |
| Hydraulic Pressure: | 40psi±1psi | Nozzle Diameter: | Φ3.18mm; |
| SS Sheet Plate: | 152.4×50.75×6.35mm | SS Mold: | 203.2×76.2×11.11mm |
| Highlight: | ASTM D4049,Resistance to Water Spray Test Equipment,ASTM D4049 test |
||
Characteristic
◆Plexiglass spray box for easy observation;
◆Precision pressure gauge shows spray pressure;
◆Stainless steel plate meets standard requirements: 152.4×50.75×6.35mm;
◆Stainless steel mold meets standard requirements: 203.2×76.2×11.11mm;
◆Stainless steel nozzle, nozzle diameter: Φ3.18mm;
◆The front end of the pressure gauge has a bypass valve to adjust the pressure: 40psi±1psi;
◆Microcomputer temperature controller, digital display, accuracy ±0.2℃, PT100 sensor;
◆The magnetic pump circulates the cooling medium, and the circulation pipe is equipped with an insulation sleeve;
◆Digital display timer to control spray time.
Technical specifications
1. Applicable standard:ASTM D4049,SH/T0643
2. Heating method of Water Spray Resistance Apparatus:electrical tube
3. Timing method:digital timer
4. Temperature control method:digital PID controller
5. Working temperature:38±0.2℃
6. Working hydraulic pressure of Water Spray Resistance Test Equipment:40psi±1psi
7. Hydraulic pressure control:adjusted by bypass valve
8. Spray method:precise nozzle
9. Total power:2.5KW
10. Power supply:AC220V/50Hz
11. Weight:43KG
II.Accessories list
| No. | Name | Specifications | Quantity | Unit |
| 1 | Main Unit Water Spay Resistance Tester | —— | 1 | Set |
| 2 | Stainless steel sheet plate | —— | 1 | PC |
| 3 | Spray shield | —— | 1 | PC |
| 4 | Mold | 1 | Set | |
| 5 | Fuse | 20A | 4 | PC |
| 6 | Thermometer | 0~50℃/0.1℃ | 1 | PC |
| 7 | Scraper | —— | 1 | PC |
