Advanced Instruments Co.,Limited
To Be Advanced in Quality and Service!
| Place of Origin: | China |
|---|---|
| Brand Name: | AI |
| Certification: | ISO |
| Model Number: | DPT-A |
| Minimum Order Quantity: | 1 set Automtic Dropping Point Test Equipment |
| Price: | Negotiable |
| Packaging Details: | Automtic Dropping Point Test Equipment packed in Hardboard |
| Delivery Time: | 30 days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 200 sets per month |
| Test Standard: | ASTM D566 | Tempeatue Control Range: | 25℃～300℃ |
|---|---|---|---|
| Operation Mode: | Automatic Test | Power Supply: | AC220V±10% 50HZ |
| Warranty: | 1 Year | Cooling Method: | Forced Air Cooling |
| Heating Method: | Heating Tube | Display: | LCD Touch Screen |
| Highlight: | Dropping Point Test Equipment,ASTM D566 dropping point test,Automtic Dropping Point Test Equipment |
||
Introduction
The Dropping Point Tester Equipment is designed and made as per the national standard of People’s Republic of China GB/T 4929 Lubricating grease- Determination of Dropping Point and ASTM D566 Standard Test Method for Dropping Point of Lubricating Grease.
Main Features:
◆This test equipment adopts metal bath heating, rapid heating and simple operation
◆It can automatically detect the dropping point of the sample, no special person is required to monitor the experiment process, and automatically notify after the experiment is over
◆The high-precision sensor can capture the dripping process of grease and get the experimental results in time
◆This Automatic dropping point test equipment uses touch screen display, clear reading and easy operation
◆Using high-precision PT100 temperature measurement sensor, the measurement accuracy is high, which is ±0.1°C
◆The dropping point test equipment is equipped with over-temperature limit function
Technical specifications
| Applicable standard | GB/T 4929,ASTM D566 |
| Temperature controlling range | 25℃～300℃ |
| Temperature controlling accuracy | 0.1℃ |
| Detection method | Automatic test and display result |
| Display method | LCD Touch screen |
| Cooling method | Forced air cooling |
| Heating method | Heating tube |
| Power supply | AC220V±10% 50HZ |
