Place of Origin: | China |
---|---|
Brand Name: | AI |
Certification: | ISO9001 |
Model Number: | GCF |
Minimum Order Quantity: | 1 Set Smoldering Combustion Characteristics Test Furnace |
Price: | Negotiable |
Packaging Details: | Smoldering Combustion Characteristics Test Furnace is packed in plywood case |
Delivery Time: | 30 days |
Payment Terms: | Western Union, T/T, L/C |
Supply Ability: | 100 sets per month |
Test Object: | External Thermal Insulation System Of Building Exterior Wall | Test Standard: | BS 8414-1,GB/T 29416 |
---|---|---|---|
Power Supply: | 220V,10A | Dimension: | 500 Mm (W) X 500 Mm (D) X 900 Mm (H) |
Weight: | 39KG | Warranty: | 1 Year |
Color: | White | Test Time: | 24 Hours |
Highlight: | Smoldering Combustion Test Furnace,BS 8414 Furnace,Combustion Test Furnace |
Product Introduction
Smoldering characteristic test furnace is mainly used in the fire performance test method of external thermal insulation system of building exterior wall. It is suitable for testing the smoldering characteristic test of thermal insulation material in building external thermal insulation system. The test method is GB/T29416-2012 "Building Exterior Wall External Insulation System Fire Performance Test Method" Appendix C, Smoldering Characteristics Test Method.
Performance characteristics
1. The Smoldering characteristic test furnace is equipped with programmable temperature controller, providing standard temperature rise curve;
2. The test time is 24 hours, and the temperature is displayed and controlled throughout the whole process;
3. Comply with the test standard BS 8414, GB/T29416-2012 "Test Method for Fire Performance of Exterior Insulation System of Building Exterior Wall" Appendix C Test Method;
4. The test software can display temperature values and temperature curves;
5. The Smoldering characteristic test furnace is provided with thermocouples in the furnace and thermocouples on the sample surface;
6. The center temperature of the sample is the same as the furnace temperature, which indicates that the sample has no tendency to smolder within the test period and temperature range;
7. During the entire test process (24 h), if the sample has a test track with self-heating characteristics, it is judged that the sample has a smoldering tendency.
Installation Requirements
1 | Model | GCF Smoldering Characteristics Test Furnace |
2 | Test standard | BS 8414,GB/T 29416 |
3 | Power supply | 220V,10A |
4 | Environmental temperature | 10°C~35°C |
5 | Dimension | 500 mm (W) x 500 mm (D) x 900 mm (H) |
6 | Weight | 39KG |
7 | Installation area | Floor-standing fume hood |
