Place of Origin: | Made in China |
---|---|
Brand Name: | AI |
Certification: | ISO |
Model Number: | COC |
Minimum Order Quantity: | 1 unit |
Packaging Details: | Wooden Case or as required |
Delivery Time: | within 10 business days |
Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability: | 100 units per month |
ASTM D92: | Automatic Cleveland Open Cup Flash Point Tester | Temperature Measurement: | Room Temperature~400ºC |
---|---|---|---|
Repeatability: | ≤8ºC | Reproducibility: | ≤17ºC |
Accuracy: | 0.1ºC | Igniting Mode: | Electric Ignition |
Dimension: | 520mm×380mm×310mm | Warranty: | 1 Year |
High Light: | Open Cup Flash Point Test Set,Flash Point Test Set,Automatic Open Cup Flash Point Test Set |
ASTM D92 Cleveland Open Cup Flash and Fire Point Tester for Petroleum Oil
Introduction:
The Cleveland Open Cup Flash and Fire Point Tester is designed and made as per the National Standard GB/T3536, ISO 2592, ASTM 92 "Test Methods for Flash Point and Fire Point of Petroleum Products (Cleveland Open Cup Methods), and T0651 "Asphalt Flash Point and Fire Point Test (Cleveland Open Cup Methods)" in the Industry Standard JTJ052 Specification and Test Methods of Bitumen and Bituminous Mixtures for Highway Engineering.
The Cleveland Open Cup Flash and Fire Point Tester is mainly applied to determine flash point of petroleum products and bituminous materials, excepting fuel oil and materials having a flash point of lower than 79 °C.
Features:
The Cleveland Open Cup Flash and Fire Point Tester comes with color LCD large screen display, full English interactive interface, no logo keyboard, Prompt menu guiding type input to the parameters as the pre-value of temperature, the sample label, atmospheric pressure and the date of the test;
Simulation trace showing the curve of heating up and test time, with English software prompt modification function with the test date, the test time and other parameters prompts;
It is equipped with standard RS-323, 485 computer interface, lower computer storing 100 sets of historical data, can be connected to computer for mass storage data and can be stored for a long time, transmission of data, the host computer can modify the lower computer parameters.
Automatic correction of the influence of atmospheric pressure on the test and calculate the correction value;
Differential detection, system deviation automatic correction;
Open the lid, ignition, detection, print data is done automatically. Electronic ignition, forced air cooling;
Can detect light ignition
Parameters:
1 |
Power supply |
AC(220±10%)V, 50Hz |
2 |
Temperature measurement |
Range:room temperature~400ºC |
3 |
Heating rate |
Correspond with GB/T3536 and ASTM D92 |
4 |
Igniting mode |
Electric ignition, |
5 |
Ambient temperature |
(10~40)ºC |
6 |
Relative humidity |
≤80% |
7 |
Maximum power consumption |
500W |
8 |
Dimension |
520mm*380mm*310mm; 13kg |
Automatic ASTM D92 Cleveland Open Cup Flash and Fire Point Tester:
