Place of Origin: | Made in China |
---|---|
Brand Name: | AI |
Certification: | ISO |
Model Number: | AIC-7305 |
Minimum Order Quantity: | 1 unit |
Price: | USD1,000~2,000 per unit |
Packaging Details: | Plywood or as required |
Delivery Time: | within 7 business days |
Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability: | 100 units per month |
Astm D1401 Demulsibility: | Water Separability Test ASTM D1401 | Water Separability: | By ASTM D1401 Demulsibility Characteristic Of Lubricant |
---|---|---|---|
Demulsibility Tester: | Demulsibility Characteristics Tester For Petroleum Oils & Synthetic Fluids | Temperature Range: | (Room Temp.∼99.9)℃ |
Temperature Control Accuracy: | ±1℃ | Resolution: | 0.1℃ |
Temperature Display: | Digital | Timing Range: | 1s∼9m 59s |
Timing Set: | Dial Control | ||
Highlight: | Water Separability test,Demulsibility Characteristics Test,Lubricating Oils Test |
Water Separability / Demulsibility Characteristics Tester for Lubricating Oils Test
Introduction of Demulsibility Tester:
1. The Demulsibility Characteristics Tester is designed and made refer to ASTM D1401 for determination of water separability of petroleum oil and synthetic liquid.
2. After a specified settling period, the degree of separation is measured by volume and the percentage of water in oil is determined. For lighter oils and synthetic fluids, the ASTM D1401 Water Separability Test is used.
3. The Demulsibility Tester is suitable to determine the water separability of petroleum oils and synthetic fluids. It can be widely used in fields of petroleum, electricity, chemical industry , colleges and scientific research institutions.
Features of Demulsibility Tester:
1. The Demulsibility Characteristics Tester adopts small bath and desktop structure. It is easy to operate and good-looking.
2. The instrument adopts electric motor to stir automatically. The temperature is uniform. It can do determination for 5 samples one by one.
3. The lifting of stirring device is convenient. The stirring paddle has good concentricity with cylinders. No tremble or touching the cylinder wall.
Specs of Demulsibility Characteristics Tester:
1 | Power supply | AC(220±10%)V, 50Hz |
2 | Temperature range | (Room temp.~99.9)ºC |
3 | Temperature control accuracy | ±1ºC |
4 | Resolution | 0.1ºC |
5 | Temperature display | Digital |
6 | Timing range | 1s~9m 59s |
7 | Timing set | Dial control |
8 | Time display | Digital |
9 | Stirring rate | (1500±15)r/min |
10 | Heating power | 1000W |
11 | Ambient temperature | (Room temp.~35)ºC |
12 | Relative humidity | ≤85% |
13 | Maximum Power consumption | 1200W |
14 | Dimension | 500mm×340mm×720mm |
Note: If the required temperature is lower than room temperature, it can equip ZL-1 portable cooler manufactured by our company.
Except the basic Demulsibility Characteristics Tester, we can also provide the automatic Demulsibility Characteristics Tester:
