Advanced Instruments Co.,Limited
To Be Advanced in Quality and Service!
| Place of Origin: | China |
|---|---|
| Brand Name: | AI |
| Certification: | ISO |
| Model Number: | NCF |
| Minimum Order Quantity: | 1 set Non-combustibility Apparatus |
| Price: | Negotiable |
| Packaging Details: | Non-combustibility Apparatus Packed with standard plywood case |
| Delivery Time: | In 40 days |
| Payment Terms: | T/T, Western Union, L/C |
| Supply Ability: | 100 sets per month |
| Referemce Standard: | ISO1182, BS476 Part 4, EN 13501, FTPC Part 1 | Color: | White Or As Requested |
|---|---|---|---|
| OEM Service: | Available | Power Supply: | 220V, 50Hz Or As Requested |
| Furnace Size: | 400 Mm (W) X 400 Mm (D) X 1200 Mm (H) | Control Unit Size: | 530 Mm (W) × 270 Mm (D) × 280 Mm (H) |
| Weight: | 65kg | Warranty: | One Year |
| Highlight: | building material testing equipment,Non-combustibility Apparatus,BS476 Part 4 |
||
Non-combustibility Apparatus is designed and manufactured in accordance with EN ISO1182 standard.
Non-combustibility Apparatus is mainly used in the non-combustibility test for building materials, and is suitable for classification of combustion performance of Class A fireproof materials.
Non-combustibility Apparatus s suitable for both composite products and materials of the components testing.
Non-combustibility Apparatus also complies to BS 476-4 & 11 and IMO FTP Part 1 standards. So it can also test UK building materials, railway materials and non-metallic products of vessel.
Features:
Non-Combustibility Apparatus measures in-combustibility and combustibility of uniform building material and non-uniform building material of actual element.
The evaluations (results) are rising temperature in the furnace, basic mass loss and ignition of specimen.
Single Zone Furnace operable at up to 900 oC with the Kanthal Ribbon Heater.
750±5oC temperature automatically control by PID and Power controller.
Non-combustibility Apparatus is provided with stabilized voltage supply for more quick temperature stabilization.
Equipped with 3 thermocouples, for temperature in furnace, specimen center, and specimen surface respectively.
360 degree rotatable and height adjustable thermocouple scanning device.
Non-combustibility Apparatus adopts Inner furnace thermocouple device to calibrate the temperature of furnace.
Parameters:
|
1 |
Dimension |
Furnace: 400 mm (W) x 400 mm (D) x 1200 mm (H) Control Unit: 530 mm (W) × 270 mm (D) × 280 mm (H) |
|
2 |
Weight |
65kg |
|
3 |
Power supply |
110V AC 60Hz / 230V AC 50Hz, 10A |
|
4 |
Ambient temperature |
10 ~ 35 Centigrade |
