Place of Origin: | CHINA |
---|---|
Brand Name: | AI |
Certification: | ISO |
Model Number: | SIT-T |
Minimum Order Quantity: | 1 SET Single Flame Source Test Equipment |
Price: | negotiable |
Packaging Details: | Single Flame Source Test Equipment packed in Plywood case |
Delivery Time: | 40 days |
Payment Terms: | Western Union, T/T, L/C |
Supply Ability: | 100 Sets per Month |
Test Standard: | EN ISO 11925-2,DIN 53438,DIN 4102-1 | Chamber Size: | Length 700mm X Width 400mm X High 600 |
---|---|---|---|
Weight: | 34KG | Warranty: | 1 Year |
Color: | White | Keyword: | Ignitability Apparatus, Single Flame Source Test Equipment |
Gas: | Propane With A Minimum Purity Of 95%. | Dimension: | 850 Mm (W) X 450 Mm (D) X 800 Mm (H) |
Highlight: | DIN 53438 equipment,Single Flame Source Test Equipment,DIN 4102-1 ignitability test equipment |
SIT-T Ignitability Apparatus.pdf
Introduction:
This ignitability test equipment is designed according to ISO11925-2, it is used to test building material under conditions in the absence of external radiation to direct impact of vertically placed samples with a small flame to determine the flammability of building products.
Standards:
Structure
1, Box paint treatment, beautiful;
2, The combustion chamber dimensions: length 700mm X width 400mm X high 600
3, The flame height can be adjusted, automatic ignition;
4, The flame burning application time and hold time can adjust from 0 to 99 minutes 99 seconds;
5, Combustion angle: 0 ° (vertical), 45 °
6, The burner can be moved in a horizontal direction;
7, Glass doors for easy observation test;
8, All fixtures are made of stainless steel; beautiful and corrosion;
9, This Ignitability and Single Flame Source Test Equipment is equipped with two types of stainless steel sample holder. With flame height measuring;
10, The equipment has high degree of test automation, test data accurate, easy to operate.
Control System:
• This ignitability test equipment is controlled by Programmable Logic Controller (PLC):
• Automatic timing, automatic detection of the flame, automatic ignition, ignition abnormal protection;
• This single flame source test equipment has LCD touch screen display;
• real-time monitoring of experimental data, queries six samples of experimental data, query alarm content.
Electrical | 230V AC 50Hz, 10A |
Ambient Temperature | 10°C to 35°C |
Dimensions | 850 mm (W) X 450 mm (D) X 800 mm (H) |
Weight | 34KG |
Applicable standards | EN ISO 11925-2,DIN 53438,DIN 4102-1 |
Gas | Propane with a minimum purity of 95%. |
