Place of Origin: | China |
---|---|
Brand Name: | AI |
Certification: | ISO |
Model Number: | AIC-5182 |
Minimum Order Quantity: | 1 set Scuffing Load Capacity Testing Equipment |
Price: | Negotiable |
Packaging Details: | Scuffing Load Capacity Testing Equipment packed in Hardboard |
Delivery Time: | 20 days |
Payment Terms: | L/C, T/T, Western Union |
Supply Ability: | 20 sets per month |
Test Standard: | ASTM D5182 | Test Method: | FZG Visual Method |
---|---|---|---|
Max. Torque: | 1Kn. M | Max. Loading Class: | 13 |
Motor Power: | 6.5/8kw | Motor Speed: | 1450/2880 R/min |
Keyward: | FZG Testing Equipment, Scuffing Load Capacity Testing Equipment | Warranty: | 1 Year |
Highlight: | Scuffing Load Capacity Testing Equipment,FZG testing equipment,ASTM D5182 |
This FZG scuffing load capacity testing equipment confirms to GB/T 13672-92 standard test method for scuffing load capacity of gears,ASTM D5182 Standard Test Method for Evaluating the Scuffing Load Capacity of Oils (FZG Visual Method), and SH/T 0366-1992 lubricant carrying capacity test method (CL-100 Gear machine method)
1 |
Max. torque |
1Kn. m |
2 |
Max. loading class |
13 |
3 |
Temperature control accuracy |
±2℃ |
4 |
Motor power |
6.5/8kw |
5 |
Motor speed |
1450/2880 r/min |
6 |
Gear box volume |
1.25L |
7 |
Heating power |
0.5X3=1.5kw |
8 |
Dimensions |
1390X750X1082mm |
2. Installation and adjustment
Make the test machine at the level of the floor and mat three horns. Put the spirit level on the test table. By adjusting the horn to make the vertical and horizontal direction error do not exceed 0.2/1000.
The fzg test machine host should be placed separately from the control cabinet to avoid the noise and pungent odor when the testing machine working. After the start of the test machine, person can not inter into the room which the machine placed.
The test procedure in accordance with the the "lubricant carrying capacity assay (CL-100 gear machine method) SH/T0306-92" provisions.
