Place of Origin: | China |
---|---|
Brand Name: | AI |
Certification: | ISO |
Model Number: | AIC-650G |
Minimum Order Quantity: | 1 set FTIR |
Price: | Negotiable |
Packaging Details: | FTIR packed in Hardboard |
Delivery Time: | 20 days |
Payment Terms: | L/C, T/T, Western Union |
Supply Ability: | 200 sets per month |
Wavenumber Range: | 7800 ~ 375 Cm-1 | Resolution: | 1 Cm-1 |
---|---|---|---|
Signal Noise Ratio: | 30000:1 | Detector: | High Resolution DTGS Detector |
Power: | 110-220V AC, 50-60Hz | Keyword: | FTIR Fourier Transform Infrared Spectroscopy |
Test Standard: | ASTM D2412 | Warranty: | 1 Year |
Highlight: | FTIR,Fourier Transform Infrared Spectroscopy,ASTM D2412 |
AIC-650G is a single beam FTIR spectrometer. This instrument is operated by a PC. It is a powerful tool to analyze the sample structure in many fields such as petroleum, chemical engineering and pharmaceutical.
High stable optical system
● The design integrates main components to an optical bench machined from a cast aluminum. Highly stable and no need for adjustment, re-moving troubles of maintenance of optical path.
● Precision machinery ensures high repeatability of every scanning. Advanced design concept is adopted in both optical path and every part
● The system’s corner cube optics provides easy operation without requiring complicated electronics and additional moving parts. In addition, many components of the spectrometer are user replaceable which saves time over the lifetime of the instrument.
● Internal dynamic collimation system and movable mirror driving system keep interferometer at optimum situation. Voice-coil driver and precision slide improves the ability of working in severe conditions.
● The spectrometer includes a container of desiccant that protects the beam splitter and other optical components from moisture damage.
Wavenumber Range | 7800 ~ 375 cm-1 |
Resolution | 1 cm-1 |
Signal Noise Ratio | 30000:1 (DTGS, resolution@4cm-1; sample and background scan for 1 min@2100cm-1) |
Detector | High resolution DTGS detector |
Beam splitter | Coated KBr |
Light Source | Long life, air cooled IR light source |
Electronic System | A/D converter of 24 bits at 500MHz, USB 2.0 |
Power | 110-220V AC, 50-60Hz |
