Basic Information
Place of Origin: CHINA
Brand Name: AI
Certification: ISO
Model Number: CRT-II
Minimum Order Quantity: 1 Set Mirco Carbon Residue Test Apparatus
Price: Negotiable
Packaging Details: Mirco Carbon Residue Test Apparatus packed in Plywood case
Delivery Time: 20 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100 Sets per Month
Get Best Price Contact Now
Test Standard: ASTM D4530 Carbon Residue Test Instrument Power Supply: AC 220V±10%, 50 Hz
Test Method: Micro Method Temperature Of Coke Chamber: 500℃
Warranty: 1 Year Size: 520mm×360mm×525mm
Heating Power: 1500W Measuring Range: 0.10%(m/m)～30.0%(m/m)
Highlight:

Carbon Residue Test Apparatus

,

Mirco Carbon Residue Test Apparatus

,

ASTM D4530

ASTM D4530 Automatic Carbon Residue Tester Micromethod

Summary
This carbon residue analyzer is designed and made as per GB/T17144-1997 Standard Test Method for Carbon Residue of Petroleum Products-Micromethod. It is suitable to determine the amount of carbon residue of petroleum products.

I. Main technical features
1. This carbon residue testing equipment adopts all-in-one structure. It consists of two parts: electrical control chamber and high temperature heating furnace. The design is simple and reasonable.
2. It adopts single chip machine system. The instrument controls the whole procedures automatically according to program preset.
3. The screen adopts all English interface. Operator can do determination by prompts on the screen even no need to read the operation manual. Easy to operate.
4. It controls the flow rate of nitrogen, temperature heating rate and preset temperature automatically. Easy to adjust the flow rate. The heating rate is accurate and temperature control is stable.
5. It collects test data and calculates results automatically. It can print and save the data according to customer’s requirements.
6. The measurement range of this instrument is 0.10%(m/m)～30.0%(m/m). The test result is equivalent to Conradson method if the carbon residue is higher than 0.10%(m/m).
7. The instrument can also be used to determine the petroleum products composed of distillate oils which carbon residue is lower than 0.10%(m/m). But the specimen shall be sampling to 10%(V/V)distillation residue according to GB/T6536 firstly.
8. It equips a electric balance to achieve the automation of sample weighing and data input.

II. Main technical specifications
1. Power supply: AC(220±10%)V, 50Hz
2. Maximum power consumption: 1600W
3. Temperature of coke chamber: 500℃
4. Temperature control accuracy: ±2℃
5. Heating power: 1500W
6. Ambient temperature: 5℃～35℃
7. Relative humidity: ≤85%
8. Dimension: 520mm×360mm×525mm


III.Accessories

No. Item Unit Qty Remarks
1 12 hole tube holder Piece 1
2 Big sample tube(Diameter 12×70mm) Piece 24
3 Small sample tube(Diameter 12×35mm) Piece 24
4 Test tube rack lift hook Piece 1
5 Air inlet pipe(ф6 PU pipe, 2m) Set 1 Used to connect the steel cylinder and main machine
6 Exhaust pipe(ф10PU pipe, 2m) Piece 1 Used to remove exhaust gas
7 The top cover of raw coke box Piece 1 Remove packaging from the equipment
8 Serial Line Piece 1 Electric balance and instrument communication line
9 15A fuse (Φ6 × 30) Piece 2
10 Electric balance(Weighing range 110g, accuracy grade I, readability 0.1mg) Set 1



Spares of ASTM D4530 Micro Method Carbon Residue Tester

Micro Method Automatic Carbon Residue Test Apparatus by ASTM D4530 0



Micro Method Automatic Carbon Residue Test Apparatus by ASTM D4530 1
