Place of Origin: | China |
---|---|
Brand Name: | AI |
Certification: | ISO |
Model Number: | AIC-1122 |
Minimum Order Quantity: | 1 set Engine Coolant Density Meter |
Price: | Negotiable |
Packaging Details: | Engine Coolant Density Meter packed in one Plywood case |
Delivery Time: | 30 days |
Payment Terms: | T/T, Western Union, L/C |
Supply Ability: | 100 Sets per Month |
Test Stadnard: | SH/T0068, ASTM D1122 | Temperature Control Range: | 20℃±0.2℃ |
---|---|---|---|
Refrigeration Method: | Air Compressor | Heating Method: | Electrical Heating Tube |
Working Units: | 2 Holes | Power Supply: | 220V/50Hz |
Color: | White | Warranty: | 1 Year |
Highlight: | ASTM D1122,Coolant Density Meter,Antifreeze Testing |
Introduction
This Density Meter is combined requirements of Chinese standards SH/T0068 and ASTM D1122.
It adopts densimeter to determine relative density of engine coolants and engine coolant concentrates.The structure is separated,and operatio is easy.It is highly improve the working efficiency.
Characteristic
1. Standard glass tube can meet requirements of ASTM test method.
2. Glass bath allows transparent observation,the operation is easy,
3. This Density Meter adopts fully closed air compressor refrigeration.
4. The cooling medium is cycles with noise-free circulating pump,
5. Heater is stainless steel.
6. Structure is separated,and it is easy to move.
7. There is hole on the cooling bath to add cooling medium,it can be added at any time if medium is lost.
8. Micro-computure controlling,PID function,digital tempeature display(continuous display during test),accuracy 0.1℃,Pt100 RTD temperature probe.
9. Contact control box is very convenient.
10. Over-heat safety protection device.There are low liquid level alarm and automatic liquid level adjuster in water bath,
Technical specifications
1 | Applicable standards | SH/T0068, ASTM D1122 |
2 | Temperature controlling range | 20℃±0.2℃ |
3 | Refrigeration mode | Air compressor |
4 | Heating mode | Electrical heating tube |
5 | Stirring mode | Motor |
6 | Working units | 2 holes |
7 | Power supply | AC220V/50Hz |
