Advanced Instruments Co.,Limited
To Be Advanced in Quality and Service!
| Place of Origin: | China |
|---|---|
| Brand Name: | AI |
| Certification: | ISO |
| Model Number: | CSC-R3 |
| Minimum Order Quantity: | 1 set ASTM D130 Copper Strip Corrosion Test Bath |
| Price: | Negotiable |
| Packaging Details: | ASTM D130 Copper Strip Test Corrosion Bath packedin Hardboard |
| Delivery Time: | 20 days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 200 sets per month |
| Test Standards: | GB/T5096,ASTM D130, ISO3735, DIN51789 | Temperature Range: | Room Temperature~150±0.1℃ |
|---|---|---|---|
| Working Units: | 6 PCS | Display: | Digital |
| Warranty: | 1 Year | Power Supply: | AC220V±10% 50HZ |
| Temp.controller: | Imported PID | Total Power: | 2KW |
| Highlight: | Corrosiveness Testing Equipment,Copper Strip Corossion Test Bath,ASTM D130 corrosion tester |
||
Introduction
The copper strip corrosion bath is suitable to determine the corrosiveness to copper of aviation gasoline, aviation turbine fuels, automotive gasoline, tractor fuels, washing solvent, kerosene distillate, lubricating oil, other hydrocarbons with Reid vapure pressure not more than 124 KPa and other petroleum products
I.Main features
1.Stainless steel water tank is easy to wash
2.Stainless steel structure with ceramic coating
3.Stainless steel bath has hydrant valve,it is effective and insulated greatly.
4.Electronic stirrer has stainless steel paddle and blade
5.Heater is stainless steel
6.Micro-computer controller,PID function,digitally display temperature(continuously display during test),accuracy 0.1℃,Pt100 temperature sensor.
7.Working temperature:room temperature~200°C
8.ASTM D130 Copper Strip Test Bath has safety device which can prevent over-heated and low liquid level very well.
II.Technical specifications
| 1 | Applicable standards | GB/T5096,ASTM D130, ISO3735, DIN51789 |
| 2 | Temperature controlling method | imported PID digital display temperature controller |
| 3 | Temperature controlling accuracy | room temperature~150±0.1℃ |
| 4 | Heating method | oil bath |
| 5 | Timing method | digital timer |
| 6 | Total power | 2KW |
| 7 | Working unit | 6 positions |
| 8 | Power supply | AC220V/50Hz |
