Place of Origin: | China |
---|---|
Brand Name: | AI |
Certification: | ISO |
Model Number: | AIC-791 |
Minimum Order Quantity: | 1 set FTM 791-3462 Panel Coking Tester |
Price: | Negotiable |
Packaging Details: | FTM 791-3462 Panel Coking Tester packed in Hardboard |
Delivery Time: | 30 days |
Payment Terms: | L/C, T/T, Western Union |
Supply Ability: | 20 sets per month |
Test Standards: | FTM 791-3462 | Oil Capacity: | 0.35L |
---|---|---|---|
Display: | Digital | Power Supply: | 220V,50Hz |
Range Of Flowmeter: | 0.2~1.0L/H | Timing Range: | 0~99.0 Hours |
Test Method: | Cooling Curve | Splash Speed: | 0~1800RPM |
Temperature Controlling: | PID Temperature Controller | Color: | Black |
Language: | English | ||
High Light: | Panel Coking Tester,FTM 791-3462,Lubricating Oil Testing |
Introduction
The panel coking tester determines the tendency of finished oils to form coke when in contact with surfaces at elevated temperatures for short periods. A sample of oil is mechanically splashed against an aluminum test panel at elevated temperature. After a specified test period, the amount of coke deposited on the panel is determined by weight.
Feature
1.The digitally controlled panel coking tester is suitable for finished lubricating oil.
2.The digital display heater independently controls the temperature of the test panel and the temperature of the oil tank. The mechanical splasher is equipped with digital display control, and the splashing speed range is 0-1800rpm.
3.The high-precision flowmeter allows the introduction of corrosive acid gas to increase the test accuracy.
4.The panel coking tester is equipped with digital timer. The hinged safety cover is equipped with an exhaust port and a safety interlock switch. When the cover is raised, the interlock switch will cut off the power supply of the drive motor to ensure safe operation.
1 | Applicable standard | FTM 791-3462 |
2 | Temperature controlling | PID temperature controller |
3 | Splash speed | 0~1800RPM,digital display |
4 | Timer | digital timer,0~99.0 hours |
5 | Flowmeter | precise flowmeter,0.2~1.0L/H |
6 | Oil capacity | 0.35L |
7 | Power supply | 220V,50Hz |
