Place of Origin: | China |
---|---|
Brand Name: | AI |
Certification: | ISO |
Model Number: | BRV |
Minimum Order Quantity: | 1 PC Bitumen Brookfield Viscometer |
Price: | Negotiable |
Packaging Details: | Bitumen Brookfield Viscometer packed in Plywood case |
Delivery Time: | 10 days |
Payment Terms: | T/T, Western Union |
Supply Ability: | 1000 PC/Month |
Measuring Range: | 100 MPa•s~2×105 MPa•s | Spindles: | No.21, 27, 28 And 29 Tota |
---|---|---|---|
Rotation Speed: | (5,10,20,50)r/min | Temperature Control Range: | 45 ℃~200 ℃ |
Dislay: | LCD | Sample Cylinder: | 20 Ml |
Test Standards: | ASTM D4402 | Application: | Measure Rotational Viscosity Of Asphalt Using Rotational Viscometer |
Power Supply: | AC 220V±10%, 50 Hz | Warranty: | 1 Year |
High Light: | Brookfield Viscometer,Bitumen Brookfield Viscometer,ASTM D4402 |
1 | Measurement range | 100 mPa•s~2×105 mPa•s (If you select the No.30 spindle, the measurement range can be extended to 4×105 mPa•s) |
2 | Rotor Specifications | No.21, 27, 28 and 29 total 4 pieces of spindles (the No.30 spindle is optional) |
3 | Rotor speed | (5,10,20,50)r/min |
4 | Measurement error | ±1% (F•S); (If you select the No.30 spindle, it will be ±3% (F•S) |
5 | Temperature control range | 45 ℃~200 ℃ |
6 | Temperature control accuracy | ±0.1 ℃ |
7 | Sample cylinder | 20 ml |
8 | Print output | Needle printer |
9 | Communication with the PC | RS232 interface |
10 | Power supply | AC 220V±10%, 50 Hz |
11 | Ambient temperature | 5 ℃~35 ℃ (when the controlling temperature is close to ambient temperature, please run the air conditioner to let the ambient temperature be 5 ℃ lower than the controlling temperature) |
12 | Relative humidity | ≤80% |
III.Accessories list
No. | Name | Quantity |
1 | Head of viscometer | 1 Set |
2 | Pedestal of instrument (having three level adjustment bolts) | 1 Set |
3 | Toothed rod | 1 Piece |
4 | Auxiliary controlling case (containing a temperature controller and a micro-printer) | 1 Set |
5 | Heater | 1 Piece |
6 | Spindle (No.21, 27, 28 and 29) | 1 for each |
7 | Connection hook and transition bolt | 1 for each |
8 | Power supply wire (250 V 6 A) | 1 Piece |
9 | Serial port wire | 1 Piece |
10 | Heater connection wire | 1 Piece |
11 | Sensor wire | 1 Piece |
12 | Sample cylinder, sample cylinder holder, sample cylinder cover, special forceps | 1 Piece |
13 | Fuse (Φ5×20) 5 A | 3 Pieces |
14 | CD for communication with a PC | 1 Piece |
